Subnet Management - vcpt7 (Application)

This topic is intended to capture Subnet Management activities over time for the vcpt7 subnet, providing a place to ask questions and make observations about the management of this subnet.

This subnet was created to help support the growth of Caffeine AI

At the time of creating this topic the current subnet configuration is as follows:

Expand
{
  "version": 51935,
  "records": [
    {
      "key": "subnet_record_vcpt7-niq42-6snup-7kcgy-cndz6-srq6n-h6vwi-oswri-a3guc-v5ssd-5qe",
      "version": 51935,
      "value": {
        "membership": [
          "6ucn7-aiavt-uucq2-cvnjf-nwmr5-vetsg-q73h7-uzqjt-klm5x-e7qxu-mqe",
          "csrkp-dimpe-7dybx-jmzjj-tjcjf-t57c4-tf4cq-cjeix-6tyah-qkyre-zae",
          "ctqez-oqvmf-kkwto-wlehz-grh5a-l7enx-7e7ds-hcn75-mpdj5-pujdj-eae",
          "uw4qe-cjsp5-sfdvk-3d5y7-ufvcj-mi6x5-f3xtd-ovphb-6ipa2-aw3pq-lqe",
          "abg3e-zrvni-lab54-xuqtf-beh5q-lijks-zlbd5-wkpwg-xua7u-e4g7y-oae",
          "xszxr-w2ae6-g2fof-f6hp4-cquvx-4vyu2-ux2tn-nij6l-b7hue-4r4kl-gqe",
          "uajv3-ocqku-n5d2z-kbw3g-mqsir-er7gs-mhsdg-27f6d-xbfjl-uugdr-cae",
          "clfor-3la2h-lohby-tfriy-xfjkf-fnqpw-kkhjw-ctb2i-tscfx-ddwu7-bqe",
          "z2tgr-ilz6g-ifi6c-3yeiq-zo5sc-humd5-vc6s6-wogpu-yj5rp-wwuta-sqe",
          "ywdqr-vd2io-gz6n3-ey4ns-h7gu7-l4huz-dk36s-fr7er-lsftp-77wde-gae",
          "ognrk-q4exl-3wf25-yrrsy-mtezk-e3qww-k6s5v-2pikz-gto6z-dyl2y-eae",
          "jux3z-ivwyz-ury64-jth4b-rrbfi-sx5af-ci72l-j4ot3-nl5jk-z4ilu-6qe",
          "f6etz-5w6fg-ho2uo-gjklb-7oxto-i2z2u-udqih-6evln-4tb5s-iliw3-7ae"
        ],
        "nodes": {},
        "max_ingress_bytes_per_message": 2097152,
        "max_ingress_messages_per_block": 1000,
        "max_block_payload_size": 4194304,
        "unit_delay_millis": 1000,
        "initial_notary_delay_millis": 300,
        "replica_version_id": "e915efecc8af90993ccfc499721ebe826aadba60",
        "dkg_interval_length": 499,
        "dkg_dealings_per_block": 1,
        "start_as_nns": false,
        "subnet_type": "application",
        "features": {
          "canister_sandboxing": false,
          "http_requests": true,
          "sev_enabled": false
        },
        "max_number_of_canisters": 0,
        "ssh_readonly_access": [],
        "ssh_backup_access": [],
        "chain_key_config": null
      }
    }
  ]
}

A new proposal with ID 137801 has been submitted, please take a look.

Click here to open proposal details

Replace nodes in subnet vcpt7

Motivation:
Replacing dead nodes

Decentralization Nakamoto coefficient changes for subnet vcpt7-niq42-6snup-7kcgy-cndz6-srq6n-h6vwi-oswri-a3guc-v5ssd-5qe:

    node_provider: 5.00 -> 5.00    (+0%)
      data_center: 5.00 -> 5.00    (+0%)
data_center_owner: 5.00 -> 5.00    (+0%)
             area: 3.00 -> 3.00    (+0%)
          country: 3.00 -> 3.00    (+0%)

Mean Nakamoto comparison: 4.33 → 4.33 (+0%)

Overall replacement impact: (gets better) the number of nodes controlled by dominant Country actors decreases from 6 to 5

Details

Nodes removed:

  • 6ucn7-aiavt-uucq2-cvnjf-nwmr5-vetsg-q73h7-uzqjt-klm5x-e7qxu-mqe [health: dead]
  • csrkp-dimpe-7dybx-jmzjj-tjcjf-t57c4-tf4cq-cjeix-6tyah-qkyre-zae [health: degraded]

Nodes added:

  • 6hkcx-vz4jv-4n33r-ywdvs-sefaa-tb2on-rac6s-4csut-iyahu-zmct2-5qe [health: healthy]
  • r7few-pljgn-iynmr-iprtj-p66dg-qpc5m-2tx4m-245oc-6dzgk-pu2wy-dae [health: healthy]
    node_provider                                                              data_center            data_center_owner            area                        country
    -------------                                                              -----------            -----------------            ----                        -------
    64xe5-tx2s3-4gjmj-pnozr-fejw2-77y5y-rhcjk-glnmx-62brf-qin5q-pqe       1    an1               1    Cloud9                  1    British Columbia       1    AU            1
    7at4h-nhtvt-a4s55-jigss-wr2ha-ysxkn-e6w7x-7ggnm-qd3d5-ry66r-cae       1    bc1               1    Continent8              1    Bucuresti         0 -> 1    BE            1
    bvcsg-3od6r-jnydw-eysln-aql7w-td5zn-ay5m6-sibd2-jzojt-anwag-mqe       1    bu1          0 -> 1    CyrusOne                1    Douglas                2    CA            1
    c5svp-7pkmf-agz5x-536k7-r7rcw-4wn3a-eo7pt-ry7su-j42uq-bvnzf-iqe       1    hk4               1    Cyxtera                 1    Flanders               1    CH            2
    fwnmn-zn7yt-5jaia-fkxlr-dzwyu-keguq-npfxq-mc72w-exeae-n5thj-oae       1    im1               1    Datacenter United       1    HongKong               1    GE            1
    g7dkt-aapqq-j3hqt-xtiys-pwapz-idulp-nwagd-zibqm-caxa4-gc23t-3qe       1    im2               1    Everyware          0 -> 1    Maribor                1    HK            1
    glrjs-2dbzh-owbdd-fpp5e-eweoz-nsuto-e3jmk-tl42c-wem4f-qfpfa-qqe       1    mb1               1    Evocative          1 -> 0    Queensland             1    IM            2
    i7dto-bgkj2-xo5dx-cyrb7-zkk5y-q46eh-gz6iq-qkgyc-w4qte-scgtb-6ae  0 -> 1    sc1               1    Green.ch           1 -> 0    Singapore              1    RO       0 -> 1
    izmhk-lpjum-uo4oy-lviba-yctpc-arg4b-2ywim-vgoiu-gqaj2-gskmw-2qe       1    se1          1 -> 0    M247               0 -> 1    Tbilisi                1    SG            1
    ma7dp-gz4tg-3c2wv-pgnsv-wna7u-czvhu-fpu47-t4dr6-gzxql-wr2m2-qae  1 -> 0    sg3               1    Manx Telecom            1    Virginia               1    SI            1
    rpfvr-s3kuw-xdqrr-pvuuj-hc7hl-olytw-yxlie-fmr74-sr572-6gdqx-iqe       1    st1               1    NEXTDC                  1    Washington        1 -> 0    US       2 -> 1
    ucjqj-jmbj3-rs4aq-ekzpw-ltjs3-zrcma-t6r3t-m5wxc-j5yrj-unwoj-mae       1    tb1               1    Nine.Ch                 1    Zurich                 2
    vegae-c4chr-aetfj-7gzuh-c23sx-u2paz-vmvbn-bcage-pu7lu-mptnn-eqe       1    zh2          0 -> 1    Posita.si               1
    x7uok-pi537-itm37-unjn3-ewkze-kuetg-kptap-nuqak-auq7z-tn5ey-dqe       1    zh4               1    Racks Central           1
                                                                               zh5          1 -> 0    hkntt                   1
1 Like

Proposal 137801 Review | Lorimer :infinity: :dog_face: - CO.DELTA △

VOTE: YES

TLDR: Replaces a down and degraded node with two up ones. The sole DFINITY node is removed, but replace with another DFINITY node, conforming to business rules relating to subnet recovery procedures. Decentralisation stats remain within IC Target Topology specification. Clustering within Europe is increased by country diversity is also increased.

Decentralisation Stats

Subnet node distance stats (distance between any 2 nodes in the subnet) →

Smallest Distance Average Distance Largest Distance
EXISTING 0 km 7377.761 km 16465.583 km
PROPOSED 1.636 km (+∞%) 6914.14 km (-6.3%) 16465.583 km

This proposal slightly reduces decentralisation, considered purely in terms of geographic distance (and therefore there’s a slight theoretical reduction in localised disaster resilience). :-1:

Subnet characteristic counts →

Continents Countries Data Centers Owners Node Providers Node Operator
EXISTING 4 10 13 13 13 13
PROPOSED 4 11 (+9.1%) 13 13 13 13

This proposal slightly improves decentralisation in terms of jurisdiction diversity. :+1:

Largest number of nodes with the same characteristic (e.g. continent, country, data center, etc.) →

Continent Country Data Center Owner Node Provider Node Operator
EXISTING 6 2 1 1 1 1
PROPOSED 7 (+16.67%) 2 1 1 1 1

See here for acceptable limits → Motion 137147

The above subnet information is illustrated below, followed by a node reference table:

Map Description
  • Red marker represents a removed node (transparent center for overlap visibility)
  • Green marker represents an added node
  • Blue marker represents an unchanged node
  • Highlighted patches represent the country the above nodes sit within (red if the country is removed, green if added, otherwise grey)
  • Light grey markers with yellow borders are examples of unassigned nodes that would be viable candidates for joining the subnet according to formal decentralisation coefficients (so this proposal can be viewed in the context of alternative solutions that are not being used)

Node Changes
Action Node Status Continent Country Data Center Owner Node Provider Node Operator
Remove 6ucn7 DOWN :bar_chart: Europe Switzerland Zurich 5 (zh5) Green.ch Reist Telecom AG sqxhb
Remove csrkp DEGRADED :bar_chart: North America United States of America (the) Washington 1 (se1) Evocative DFINITY Stiftung xph6u
Add 6hkcx UP :bar_chart: Europe Switzerland Zurich 2 (zh2) Everyware DFINITY Stiftung wqyl3
Add r7few UP :bar_chart: Europe Romania Bucharest (bu1) M247 Iancu Aurel c5ssg
Other Nodes
Node Status Continent Country Data Center Owner Node Provider Node Operator
uajv3 UP :bar_chart: Oceania Australia Queensland 1 (sc1) NEXTDC ANYPOINT PTY LTD 6jel7
z2tgr UP :bar_chart: Europe Belgium Antwerp (an1) Datacenter United NODAO k4aor
clfor UP :bar_chart: North America Canada Vancouver (bc1) Cyxtera Blockchain Development Labs feb2q
ctqez UP :bar_chart: Europe Switzerland Zurich 4 (zh4) Nine.Ch Tomahawk.vc paxme
ognrk UP :bar_chart: Asia Georgia Tbilisi 1 (tb1) Cloud9 George Bassadone yhfy4
jux3z UP :bar_chart: Asia Hong Kong HongKong 4 (hk4) hkntt Web3game dg7of
abg3e UP :bar_chart: Europe Isle of Man Douglas 1 (im1) Manx Telecom Blue Ant LLC 4isre
ywdqr UP :bar_chart: Europe Isle of Man Douglas 2 (im2) Continent8 Zarety LLC ylbc3
f6etz UP :bar_chart: Asia Singapore Singapore 3 (sg3) Racks Central Protocol16 vicvb
uw4qe UP :bar_chart: Europe Slovenia Maribor (mb1) Posita.si BlockFinance ozfkj
xszxr UP :bar_chart: North America United States of America (the) Sterling (st1) CyrusOne MI Servers tcn4t


You may wish to follow the CO.DELTA known neuron if you found this analysis helpful.

CO.DELTA △

We’re a verifiably decentralised collective who review IC deltas (changes applied by NNS proposals). We follow a common code:

  • Look: We observe the details and context of NNS proposals
  • Test: We test and verify the claims made by those proposals
  • Automate: We automate as much as possible by building increasingly sophisticated tools that streamline and strengthen the reviewal process.

Every vote cast by CO.DELTA is the result of consensus among diligent, skilled and experienced team members acting independently. The CO.DELTA neuron follows the vote of D-QUORUM on NNS topics that the CO.DELTA team does not handle directly. You can therefore follow CO.DELTA on all topics and rely on the highest quality of vote.


Note that this analysis involved data provided by the IC-API, which is not open source. I’m in the process of switching over to more verifiable sources of this sort of information for future proposal reviews. See here for related discussion.

Proposal 137801 | Tim - CodeGov

Vote: Adopt

This proposal replaces node 6ucn7 which appears in the dashboard as “Offline”, and node csrkp which appears in the dashboard as “Degraded”. As seen in the Node Provider Rewards tool, node csrkp has had a 100% block failure rate for the last 2 full days for which data are shown.

The replacement nodes appear in the dashboard as “Healthy”. As shown in the proposal, decentralisation parameters are unchanged and remain within the requirements of the target topology.

About CodeGov
CodeGov has a team of developers who review and vote independently on the following proposal topics: IC-OS Version Election, Protocol Canister Management, Subnet Management, API Boundary API Boundary Node Management, Node Admin and Participant Management. The CodeGov NNS known neuron is configured to follow our reviewers on these technical topics. We also have a group of Followees who vote independently on the Governance and the SNS & Neurons' Fund topics. We strive to be a credible and reliable Followee option that votes on every proposal and every proposal topic in the NNS. We also support decentralisation of SNS projects such as WaterNeuron, KongSwap, and Alice with a known neuron and credible Followees.

Learn more about CodeGov and its mission at codegov.org.

Proposal #137801 — ZoLee | CodeGov

Vote: Adopted

Reason:
Replaces 2 nodes one Degraded node with IC_Replica_SlowerServerThanSubnetMedian status csrkp from SE1 DC in Washington owned by Dfinity with healthy unassigned node 6hkcx from Zurich owned also by Dfinity, while dead node 6ucn7 from ZH5 DC in Zurich is being replaced with healthy unassigned node r7few from Bucharest with slight improvement to decentralization.

About CodeGov
CodeGov has a team of developers who review and vote independently on the following proposal topics: IC-OS Version Election, Protocol Canister Management, Subnet Management, Node Admin, and Participant Management. The CodeGov NNS known neuron is configured to follow our reviewers on these technical topics. We also have a group of Followees who vote independently on the Governance and the SNS & Neuron's Fund topics. We strive to be a credible and reliable Followee option that votes on every proposal and every proposal topic in the NNS. We also support decentralization of SNS projects such as WaterNeuron, KongSwap, and Alice with a known neuron and credible Followees.

Learn more about CodeGov and its mission at codegov.org.

Proposal 137801 Review | Malith H - CO.DELTA △

VOTE: YES :white_check_mark:

TLDR:
This proposal removes 2 node(s) one degraded and one offline from Zurich 5, Washington 1 and adds 2 replacement node(s) in Zurich 2, Bucharest. Decentralisation stats remian the same. I vote to adopt.

Subnet Details
Property Value
ID vcpt7…
Type application
Memory Usage 0.00 GB
Running Canisters 0
Description N/A
Provider Changes
Removed Added
Reist Telecom AG DFINITY Stiftung
DFINITY Stiftung Iancu Aurel
Location Changes
Removed Added
Europe, Zurich 5 Europe, Zurich 2
North America, Washington 1 Europe, Bucharest
Nodes Removed 2
Node ID Status Provider Data Center Location
6ucn7… DOWN Reist Telecom AG zh5 Zurich 5
csrkp… DEGRADED DFINITY Stiftung se1 Washington 1
Nodes Added 2
Node ID Status Provider Data Center Location
6hkcx… UNASSIGNED DFINITY Stiftung zh2 Zurich 2
r7few… UNASSIGNED Iancu Aurel bu1 Bucharest

:white_check_mark: Passes:

:white_check_mark: Node 6ucn7…: Health check passed.

:white_check_mark: Node 6ucn7…: Remove from Subnet check passed.

:white_check_mark: Node csrkp…: Health check passed.

:white_check_mark: Node csrkp…: Remove from Subnet check passed.

:white_check_mark: Node 6hkcx…: Replacement Status check passed.

:white_check_mark: Node 6hkcx…: Not assigned to any subnet.

:white_check_mark: Node r7few…: Replacement Status check passed.

:white_check_mark: Node r7few…: Not assigned to any subnet.

You may wish to follow the CO.DELTA known neuron if you found this analysis helpful.

CO.DELTA

We’re a verifiably decentralised collective who review IC deltas (changes applied by NNS proposals). We follow a common code:

  • Look: We observe the details and context of NNS proposals
  • Test: We test and verify the claims made by those proposals
  • Automate: We automate as much as possible by building increasingly sophisticated tools that streamline and strengthen the reviewal process.

Every vote cast by CO.DELTA is the result of consensus among diligent, skilled and experienced team members acting independently. The CO.DELTA neuron follows the vote of D-QUORUM on NNS topics that the CO.DELTA team does not handle directly. You can therefore follow CO.DELTA on all topics and rely on the highest quality of vote.

Proposal 137801 Review | aligatorr - CO.DELTA △

VOTE: YES

TLDR: Replaces unhealthy node.

  • Interconnected node providers detected: Blue Ant LLC, Zarety LLC :warning:
  • Proposed topology Nakamoto Coefficient stayed the same as on current topology.
Node Changes 2 removed, 2 added
Node ID Status Country City Node Provider Data Center Data Center Owner
csrkp-dimpe-7dybx-jmzjj-tjcjf-t57c4-tf4cq-cjeix-6tyah-qkyre-zaer7few-pljgn-iynmr-iprtj-p66dg-qpc5m-2tx4m-245oc-6dzgk-pu2wy-dae DEGRADED → UP USRO WashingtonBucuresti DFINITY StiftungIancu Aurel se1bu1 EvocativeM247
6ucn7-aiavt-uucq2-cvnjf-nwmr5-vetsg-q73h7-uzqjt-klm5x-e7qxu-mqe6hkcx-vz4jv-4n33r-ywdvs-sefaa-tb2on-rac6s-4csut-iyahu-zmct2-5qe DOWN → UP CHCH ZurichZurich Reist Telecom AGDFINITY Stiftung zh5zh2 Green.chEveryware
Current Nakamoto Coefficients and Topology, avg = 4.50
Attribute Nakamoto Coefficient Identical attribute values Max allowed identical values Unique Counts
Country 3 2 10
Data Center 5 1 13
Data Center Owner 5 1 13
Node Provider ID 5 1 13
Proposed Nakamoto Coefficients and Topology, avg = 4.50
Attribute Nakamoto Coefficient Identical attribute values Max allowed identical values Unique Counts
Country 3 2 11
Data Center 5 1 13
Data Center Owner 5 1 13
Node Provider ID 5 1 13

You may wish to follow the CO.DELTA known neuron if you found this analysis helpful.

CO.DELTA

We’re a verifiably decentralised collective who review IC deltas (changes applied by NNS proposals). We follow a common code:

  • Look: We observe the details and context of NNS proposals.
  • Test: We test and verify the claims made by those proposals.
  • Automate: We automate as much as possible by building increasingly sophisticated tools that streamline and strengthen the reviewal process.

Every vote cast by CO.DELTA is the result of consensus among diligent, skilled and experienced team members acting independently. The CO.DELTA neuron follows the vote of D-QUORUM on NNS topics that the CO.DELTA team does not handle directly. You can therefore follow CO.DELTA on all topics and rely on the highest quality of vote.

1 Like

Proposal 137801 – LaCosta | CodeGov

Vote: ADOPT

Summary:
One of the replaced nodes is a DFINITY node which is flagged as Degraded with a status of IC_Replica_SlowerServerThanSubnetMedian. Looking at the Node Provider Rewards we can see that this node has 100% failure rate between the 7th and the 9th of August. This node is replaced by another DFINITY node.

The proposal replaces two nodes, one offline and another degraded, on subnet vcpt7:

  • Removed Nodes: nodes 6ucn7, Dashboard Status: Offline and csrkp, Dashboard Status: Degraded

  • Added Nodes: nodes 6hkcx, Dashboard Status: Healthy and Not assigned to a subnet and r7few, Dashboard Status: Healthy and Not assigned to a subnet

The decentralization remains unchanged across all features

The subnet is within the current approved IC Target Topology so no issues here.

About CodeGov
CodeGov has a team of developers who review and vote independently on the following proposal topics: IC-OS Version Election, Protocol Canister Management, Subnet Management, Node Admin, and Participant Management. The CodeGov NNS known neuron is configured to follow our reviewers on these technical topics. We also have a group of Followees who vote independently on the Governance and the SNS & Neuron's Fund topics. We strive to be a credible and reliable Followee option that votes on every proposal and every proposal topic in the NNS. We also support decentralization of SNS projects such as WaterNeuron, KongSwap, and Alice with a known neuron and credible Followees.

Learn more about CodeGov and its mission at codegov.org.
